Ozone Aging Test Chamber
and High-Precision Customization
Fully customized by your sample size, quantity and on-site conditions. Ozone is generated by high-precision UV or silent discharge tubes with a continuously adjustable 10~1000 pphm concentration, supporting both static and dynamic test modes, fully meeting GB/T 7762, ISO 1431 and ASTM D1149.
Ozone Concentration Range
Concentration Control Deviation
Temperature Control Range
Humidity Control Range
Customization Capabilities
Full-Dimensional Non-standard Customization
Precisely Matching Test Requirements
Fully customizable dimensions, structure, ozone generation, control systems and safety protection to match your test conditions.
Size & Space Customization
- Internal effective space customized by sample size and quantity
- Static/dynamic tension fixture structure designed on demand
- 360° rotating sample rack with adjustable rotation speed
Customization Parameter Range Reference
Beyond standard equipment, we offer full non-standard customization around your sample size, test requirements and on-site conditions. Below is the customizable core parameter range; contact an engineer for specifics. Parameters are measured at 25°C ambient, no-load.
| Parameter Category | Technical Indicator | Customization Range / Specification |
|---|---|---|
| Performance | Temperature Range |
0℃~+70℃ or RT+10℃~+70℃
* Supports extended customization to a wider temperature range
|
| Humidity Range |
30%~98% RH
* Provides stable humidity control according to different standard requirements
|
|
| Fluctuation / Uniformity | Temperature fluctuation ≤±0.5℃, uniformity ≤±2.0℃; ozone concentration deviation ≤±5% | |
| Ozone Concentration Range |
10~1000 pphm continuously adjustable
* Supports 5~500 ppm high-concentration customization
|
|
| Tension Test Mode | Static tension, dynamic tension (tension frequency 0.5Hz, turntable speed 1r/min) | |
| System Configuration | Ozone Generator | High-precision silent discharge tube or UV lamp, low noise, safe and efficient |
| Ozone Sensor | Imported electrochemical sensor (e.g. UK Alphasense), high detection accuracy, fast response | |
| Controller | Imported programmable touch controller with independent control of ozone, temperature and humidity | |
| Temperature & Humidity Sensor | High-precision platinum resistance PT100Ω and polymer humidity sensor | |
| Circulation System | Temperature-resistant low-noise air-conditioning motor, multi-blade centrifugal fan | |
| Communication Interface | RS232/RS485/Ethernet optional, supporting host monitoring and data recording export | |
| Materials | Outer Cabinet Material | Premium carbon steel plate, phosphated electrostatic spraying, color customizable |
| Inner Cabinet Material |
SUS304 stainless steel plate
* SUS316L material or Teflon anti-corrosion coating available for corrosive tests
|
|
| Insulation Material | Rigid polyurethane foam, thickness customizable by temperature requirements | |
| Door Frame Insulation | Double-layer high/low temperature resistant silicone rubber door seal | |
| Dimensions & Structure | Internal Dimensions / Volume |
Fully customized by sample size, quantity and on-site space
* From miniature test chambers to large walk-in test rooms
|
| Door Design | Single/double/sliding/lifting door options; size and position customized on demand | |
| Load Capacity | Base plate load capacity customizable from tens of kilograms to several tons; rails and weighbridges can be pre-embedded | |
| Installation Method | Integrated/split type optional, installation scheme designed by on-site space | |
| Safety Protection | Standard Protection | Ozone tail gas decomposition and discharge system, door electromagnetic lock interlock, leakage/short-circuit/over-temperature/water shortage protection, motor overheat protection |
| Special Protection | Explosion-proof relief, fire alarm, smoke alarm and other special safety functions customizable by industry needs | |
| Power Requirements | AC380V±10% 50±0.5Hz three-phase four-wire or AC220V and other power specifications customizable by on-site conditions | |
| Standard Configuration | Sample rack, test lead holes, lighting, etc., configurable by demand | |
Compliant with the Following Test Standards
- GB/T 7762-2014 Ozone Cracking Resistance — Static Tension Test
- GB/T 13642-2015 Ozone Cracking Resistance — Dynamic Tension Test
- GB/T 2951.21-2008 General Test Methods for Cable Materials
- ISO 1431-1:2012 Rubber Ozone Cracking Resistance Test
- ASTM D1149-2020 Ozone Aging Controlled Environment Cracking Test
- GB/T 11039.3-2005 Textile Resistance to Atmospheric Ozone Test
- DIN 53509-2:2001 Dynamic Stress Ozone Resistance Determination
- GJB 150.x Military Equipment Laboratory Environmental Test Methods
Core Equipment Craftsmanship
Extremely Rigorous Manufacturing Craftsmanship
From full-welded liner to ozone pipeline sealing and anti-corrosion coating, every chamber is built to precision-instrument standards.
AI Intelligent Ozone Closed-Loop Control
A high-precision imported electrochemical sensor with PID closed-loop control monitors and compensates ozone generation in real time, keeping concentration fluctuation within ±5%.
Higher Requirements for Craftsmanship Standards?
Every unit is rigorously tested from material selection to delivery. Tell us your requirements and we will provide one-on-one craftsmanship customization.
Customization Process
Custom Chamber Customization
Standard Delivery Process
Customizing a chamber is like tailoring a suit. Our rigorous 5-step process, from requirements to delivery, ensures the equipment fully matches your test requirements.
2Hours
Rapid preliminary solution
100%
Meets testing standard specifications
72h
Factory extreme aging run
1Year
Free full-machine warranty
Senior Engineering Team On-site
Large walk-in test rooms are provided with factory-engineer on-site survey, installation and SAT acceptance services.
Requirements Alignment & On-site Survey
Interviews lock in sample size, heat generation and key parameters. For large equipment, engineers conduct on-site site and power surveys.
Design & Confirmation
3D modeling and CFD simulation produce CAD and layout drawings plus system calculations. We then finalize the technical agreement and acceptance standards.
Flexible Production & Precision Manufacturing
Using international first-tier components, from laser-cut sheet metal to nitrogen-filled oxygen-free pipe welding. The stainless steel liner is fully argon-arc welded to prevent cracking or leakage.
Pre-shipment Inspection & Acceptance
A continuous 72-hour no-load/loaded operation test verifies performance, with multi-point calibration of temperature uniformity and a full factory inspection report.
On-site Delivery & SAT Acceptance
Dedicated transport with on-site assembly, commissioning and system integration, plus third-party metrology verification and operation training.
Start Non-standard Assessment NowVertical Industry Solutions
Covering Multi-industry Application Scenarios
Providing Customized Environmental Simulation Solutions
Covering rubber, cable, automotive and textile & coating industries, providing reliable ozone test solutions that meet industry standards.
Rubber Product Ozone Aging & Cracking Test
For tire sidewalls, rubber hoses, sealing rings and other rubber products, precise ozone concentration and temperature/humidity control evaluate ozone cracking resistance under static tension or dynamic strain, per GB/T 7762 and ISO 1431 for formulation R&D and antioxidant evaluation.
