Air-Change Aging Test Chamber
and Non-standard Customization
Fully customized by your sample size and on-site conditions, from conventional cable aging to large polymer material accelerated aging. Supporting an RT+10℃~+300℃ extreme temperature range and 1~200 times/hour air-change regulation, fully meeting GB/T 3512, GB/T 7141 and UL 1581.
Air Change Rate
Temperature Range
Temperature Fluctuation
Temperature Uniformity
Customization Capabilities
Full-Dimensional Non-standard Customization
Precisely Matching Test Requirements
Fully customizable dimensions, structure, air-change system, control functions and safety protection to match your test conditions.
Size & Space Customization
- Internal effective space customized by sample size and quantity
- Door size, position and opening method designed on demand
- Observation window size, quantity and position flexibly configured
Customization Parameter Range Reference
Beyond standard chambers, we offer full non-standard customization around your sample size, test requirements and on-site conditions. Below is the customizable core parameter range; contact an engineer for specifics. Parameters are measured at 25°C ambient, no-load.
| Parameter Category | Technical Indicator | Customization Range / Specification |
|---|---|---|
| Performance | Temperature Range |
RT+10℃~+200℃ / +250℃ / +300℃
* Select corresponding temperature segment by different polymer material aging requirements
|
| Air Change Rate |
1~100 times/h (continuously adjustable)
* UL cable and other special standards can customize high air change 20~200 times/h
|
|
| Fluctuation / Uniformity | Temperature fluctuation ≤±0.5℃, temperature uniformity ≤±2.0℃ (no-load) | |
| Heating Rate | Standard: 1.0~3.0℃/min (heating rate can be specially customized on customer request) | |
| Control System | Controller | Intelligent high-precision digital PID microcomputer temperature controller, supporting time timing and automatic shutdown |
| Air Change Control | Automatic instrument control, equipped with precision flowmeter, supporting watt-hour meter measurement of air change rate | |
| Temperature Sensor | Platinum resistance PT100Ω | |
| Heating System | Stainless steel finned electric heating tube, PID intelligent temperature control with SSR non-contact output | |
| Circulation System | High-temperature-resistant long-shaft motor, multi-blade centrifugal fan, horizontal diffused air supply | |
| Specimen Turntable | Double-layer stainless steel rotating rack, speed 1~10r/min (360° rotation) | |
| Materials | Outer Cabinet Material | Premium carbon steel plate, phosphated electrostatic spraying, color customizable |
| Inner Cabinet Material |
SUS304 stainless steel plate
* SUS316L or Teflon anti-corrosion coating optional for corrosive tests
|
|
| Insulation Material | Rigid polyurethane foam, thickness customizable by temperature requirements | |
| Door Frame Seal | Double-layer high-temperature resistant silicone rubber door sealing strip | |
| Dimensions & Structure | Internal Dimensions / Volume |
Fully customized by sample size, quantity and on-site space
* From micro chambers to large walk-in rooms
|
| Door Design | Single/double/sliding/lifting door options, size and position customized on demand | |
| Load Capacity | Base plate load capacity customizable from tens of kilograms to several tons; rails and weighbridges can be pre-embedded | |
| Installation Method | Integrated / split type optional; installation plan designed by on-site space | |
| Safety Protection | Standard Protection | Leakage, short-circuit, over-temperature, water shortage, motor overheat, compressor over-pressure/overload/over-current protection, controller power-failure memory |
| Special Protection | Explosion-proof relief, fire alarm and smoke alarm customized by industry requirements | |
| Power Requirements | AC380V±10% 50±0.5Hz three-phase four-wire, or AC220V and other power specifications customizable by on-site conditions | |
| Standard Configuration | Sample rack, test lead holes, lighting, etc., configurable on demand | |
Compliant with the Following Test Standards
- GB/T 3512 Rubber - Hot Air Accelerated Aging Test
- GB/T 7141 Plastics - Thermal Aging Test Method
- JB/T 7444 Air-Heat Aging Test Chamber Standard
- UL 1581 Wire & Cable Reference Standard
- ASTM D2436 Insulating Material Hot Air Aging
- ASTM D573 Rubber - Hot Air Aging Test
- JIS K7212 Plastics - Thermal Aging Test
- GB/T 11026 Insulating Material Thermal Endurance Evaluation
Core Equipment Craftsmanship
Extremely Rigorous Manufacturing Craftsmanship
From full-weld liners to air-change control and explosion-proof design, every chamber is built to precision-instrument standards.
AI + Dual PID Intelligent Temperature Control
A new-generation AI algorithm with dual PID closed-loop control dynamically compensates for sample heat load, achieving temperature fluctuation ≤±0.1℃.
Higher Requirements for Craftsmanship Standards?
Every unit is rigorously tested from material selection to delivery. Tell us your requirements and we will provide one-on-one craftsmanship customization.
Customization Process
Custom Chamber Customization
Standard Delivery Process
Customizing a chamber is like tailoring a suit. Our rigorous 5-step process, from requirements to delivery, ensures the equipment fully matches your test requirements.
2Hours
Rapid preliminary solution
100%
Meets testing standard specifications
72h
Factory extreme aging run
1Year
Free full-machine warranty
Senior Engineering Team On-site
Large walk-in test rooms are provided with factory-engineer on-site survey, installation and SAT acceptance services.
Requirements Alignment & On-site Survey
Interviews lock in sample size, heat generation and air-change parameters. For large equipment, engineers conduct on-site site and power surveys.
Design & Confirmation
3D modeling and CFD simulation produce CAD and layout drawings plus thermodynamic calculations. We then finalize the technical agreement and acceptance standards.
Flexible Production & Precision Manufacturing
Using international first-tier components, from laser-cut sheet metal to nitrogen-filled oxygen-free pipe welding. The stainless steel liner is fully argon-arc welded to prevent cracking or leakage.
Pre-shipment Inspection & Acceptance
A continuous 72-hour no-load/loaded operation test verifies performance, with multi-point calibration of temperature uniformity and a full factory inspection report.
On-site Delivery & SAT Acceptance
Dedicated transport with on-site assembly, commissioning and system integration, plus third-party metrology verification and operation training.
Start Non-standard Assessment NowVertical Industry Solutions
Covering Multi-industry Application Scenarios
Providing Customized Environmental Simulation Solutions
Covering rubber & plastics, wire & cable, automotive and electronics & semiconductor, with reliable environmental test solutions that meet industry standards.
Polymer Material Thermo-Oxidative Accelerated Aging Test
For rubber, plastics, films and other polymer materials, thermo-oxidative accelerated aging per GB/T 3512 and GB/T 7141 simulates long-term thermal oxidation with preheated fresh air, evaluating tensile strength, hardness and appearance.
Need more detailed aging test technical materials?
Including rubber thermo-oxidative aging, UL 1581 interpretation, polymer thermal aging guides and non-standard customization cases.
Customer Cases
Proven by Strength
Quality Witnessed by Delivered Cases
A selection of delivered environmental testing cases across aerospace, new energy batteries, automotive electronics and semiconductors, showcasing real projects and testing capabilities.
